Benefits of Wärtsilä sewage treatment plants

Cost-effective, environmental friendly & safe answer for every ship to dispose of waste water at sea
Proven effluent quality: clean and safe effluent, suitable for discharging overboard
Low operational costs with:
- minimal maintenance & spare parts required
- minimal human intervention during operation

Simple & robust construction
Compatible with gravity & vacuum collection systems
Collecting tank integral part of STP

Main features

IMO 227(64) & MED certified
Single power supply input point
Solids handling centrifugal discharge pump
Chemical disinfection and de-chlorination
Automatic control
Compact design

Models

STC 13 line

System	IMO certified (litres/day)	Dimensions (LxWxH in mm)			Weight full (kg)
STC-01-13	1740	1890	1400	1181	1550
STC-02-13	3120	2518	1863	1336	3030
STC-03-13	4660	2622	1863	1681	3959
STC-04-13	6010	2722	2080	1821	5027
STC-06-13	9360	3072	2280	1971	7367

STC 14 line

System	IMO certified (litres/day)	Dimensions (LxWxH in mm)			Weight full (kg)
STC-08-14	11840	3000	2670	2000	9294
STC-10-14	15810	3400	2750	2000	11314
STC-13-14	20830	4400	2750	2000	15036
STC-15-14	25704	3700	3215	2300	17836
STC-20-14	33974	4620	3215	2300	22422
STC-25-14	40778	4620	3490	2500	27446
STC-30-14	47422	5012	3470	2700	30898
STC-40-14	64150	6012	3915	2680	43614
STC-50-14	80182	7000	4145	2900	55526
STC-60-14	100800	7000	4180	3500	69754

Scope of supply

As standard

Main tank
Air compressor
Discharge pump
Electrical control panel
Chlorination & dechlorination systems

Optional

Fitted vacuum sewage collection equipment
Conditioning water flow meter
Standby compressor (mounted)
Standby discharge pump (mounted)
Maceration
Separate sewage feed system
Retrofit options available to aid installation
